MPL-AY1050

Molded Construction
Magnetically Shielded

High Performance
Low Audible Noise

Soft Saturation
Stable Over High Temperatures

The MPL-AY Series offers Low DCR/ACR and the ability to handle high current.

Inductor Selector Tool

Buck Sync Image Buck Non-Sync Image Boost Sync Image Boost Non-Sync Image
*Based on Nominal Values
Show Columns
Status
MPS Inventory
L (µH)
RDC (typ) (mΩ)
IR (40K) (A)
Isat (30%) (A)
Operating Temp (max) (℃)
A Dimension (L) (mm)
B Dimension (W) (mm)
C Dimension (H) (mm)
Construction
MPSafe
MPL
Product URL
RESET TABLE
L (µH)
RDC (typ) (mΩ)
IR (40K) (A)
Isat (30%) (A)
Operating Temp (max) (℃)
A Dimension (L) (mm)
B Dimension (W) (mm)
C Dimension (H) (mm)
Construction
MPS
0.47
0.68
1.0
1.5
2.2
3.3
4.7
5.6
6.8
10
+155°C
11.0
10.0
4.80
SMD
Is MPSafe Has MPL Product URL

MPL-AY1050-R47
ACTIVE
Molded Inductor 0.47µH
 Buy On MPS 0.47 1.25 25 41 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-r47.html
MPL-AY1050-R68
ACTIVE

Molded Inductor 0.68µH

 Buy On MPS 0.68 1.75 23 36 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-r68.html
MPL-AY1050-1R0
ACTIVE
Molded Inductor 1.0µH
 Buy On MPS 1.0 2.6 19 33 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-1r0.html
MPL-AY1050-1R5
ACTIVE
Molded Inductor 1.5µH
 Buy On MPS 1.5 3.4 17 26.5 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-1r5.html
MPL-AY1050-2R2
ACTIVE
Molded Inductor 2.2µH
 Buy On MPS 2.2 4.9 15 19.5 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-2r2.html
MPL-AY1050-3R3
ACTIVE
Molded Inductor 3.3µH
 Buy On MPS 3.3 8 12.5 17 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-3r3.html
MPL-AY1050-4R7
ACTIVE
Molded Inductor 4.7µH
 Buy On MPS 4.7 9.5 11.5 15 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-4r7.html
MPL-AY1050-5R6
ACTIVE
Molded Inductor 5.6µH
 Buy On MPS 5.6 13 9.8 14 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-5r6.html
MPL-AY1050-6R8
ACTIVE
Molded Inductor 6.8µH
 Buy On MPS 6.8 15 9 13 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-6r8.html
MPL-AY1050-100
ACTIVE
Molded Inductor 10µH
 Buy On MPS 10 19 7.8 12 155°C 11.0 10.0 4.80 SMD 1 0 https://www.monolithicpower.com/en/products/inductor/molded-optimized-for-mps-dc-dc/mpl-ay-molded/mpl-ay1050-100.html
No more parts left for display.
