MPQ6653A-AEC1

MPQ6653A-AEC1

35V/1.2A, Single-Phase BLDC Motor Driver with Integrated Hall Sensor in TSOT23-6-SL and TSOT23-6 Packages, AEC-Q100 Qualified

Datasheet

Description

The MPQ6653AGJS-AEC1 and MPQ6653AGJ-AEC1 are single-phase brushless DC (BLDC) motor drivers with integrated power MOSFETs and an embedded Hall sensor. They drive a single-phase BLDC motor, with up to 1.2A of peak coil current. The input voltage (V_IN) range is between 3.5V and 35V.

The MPQ6653AGJS-AEC1 and MPQ6653AGJ-AEC1 control the motor speed through the pulse-width modulation (PWM) signal or the DC voltage on the PWM pin. The devices feature configurable soft commutation, a Hall offset angle, and speed curve configurations.

The FG/RD pin acts as either a rotating speed indicator (FG) based on the embedded Hall sensor’s output, or locked-rotor indicator (RD) if locked-rotor protection is triggered.

Rich protections include input over-voltage protection (OVP), under-voltage lockout (UVLO), locked-rotor protection, over-current protection (OCP), and thermal shutdown protection.

The MPQ6653AGJS-AEC1 is available in a TSOT23-6-SL package, and the MPQ6653AGJ-AEC1 is available in a TSOT23-6 package. They are available in AEC-Q100 Grade 1.

The MPQ6653AGDTE-AEC1 is functionally the same part, but it is available in a wettable-flank TQFN-6 (2mmx3mm) package.

Features & Benefits

3.5V to 35V Operating Input Voltage (V_IN) Range
On-Chip Hall Sensor
Integrated High-Side MOSFET (HS-FET) and Low-Side MOSFET (LS-FET): 960mΩ
Selectable Open-Loop or Closed-Loop Speed
Configurable Curves
Configurable Starting Duty Cycle
Configurable Stopping Duty Cycle
Soft Commutation
Configurable Soft Acceleration Time
Configurable Hall Leading/Lag Angle
Supports 50Hz to 100kHz Pulse-Width Modulation (PWM) Input Frequency or DC Input
Automatic Reverse Current Block
24kHz PWM Output Frequency
Configurable Current Limit
Short-Circuit Protection (SCP)
Over-Voltage Protection (OVP)
Standby Mode
Selectable FG or RD Output
Available in TSOT23-6-SL and TSOT23-6 Packages
Available in AEC-Q100 Grade 1

Active Part Numbers:

MPQ6653AGJS-xxxx-AEC1-Z MPQ6653AGJS-xxxx-AEC1-P MPQ6653AGJ-xxxx-AEC1-Z MPQ6653AGJ-xxxx-AEC1-P MPQ6653AGJS-0000-AEC1-Z MPQ6653AGJS-0000-AEC1-P MPQ6653AGJ-0000-AEC1-Z MPQ6653AGJ-0000-AEC1-P

Meaning of P & Z

Related Products

MPQ6653AGDTE-AEC1 35V/1.2A, Single-Phase BLDC Motor Driver with Integrated Hall Sensor in a TQFN-6 (2mmx3mm) WF Package, AEC-Q100 Qualified

The MPQ6653AGDTE-AEC1 is a single-phase brushless DC (BLDC) motor driver with integrated power MOSFETs and an embedded Hall sensor. It drives a single-phase brushless DC (BLDC) motor, with up to 1.2A of peak coil current. The input voltage (V_IN) range is between 3.5V and 35V.

The MPQ6653AGDTE-AEC1 controls the motor speed through the pulse-width modulation (PWM) signal or the DC voltage on the PWM pin. The device features configurable soft commutation, a Hall offset angle, and speed curve configurations.

The FG/RD pin acts as either a rotating speed indicator (FG) based on the embedded Hall sensor’s output, or locked-rotor indicator (RD) if locked-rotor protection is triggered.

Rich protections include input over-voltage protection (OVP), under-voltage lockout (UVLO), locked-rotor protection, over-current protection (OCP), and thermal shutdown protection.

The MPQ6653AGDTE-AEC1 is available in wettable-flank TQFN-6 (2mmx3mm) package. It is available in AEC-Q100 Grade 1.

The MPQ6653AGJS-AEC1 and MPQ6653AGJ-AEC1 are functionally the same part, but they are available in TSOT23-6-SL and TSOT23-6 packages, respectively.
