MP2695

New

I2C-Controlled, Single-Cell Switching Charger with JEITA Profile

Learn about our Evaluation Kit
Talk to an Engineer or get a Quote

Product Description

The MP2695 is a highly integrated, flexible, switch-mode battery charging management device designed for a single-cell Li-ion and Li-polymer battery used in a wide range of portable applications.

The MP2695 integrates three battery-charging phases: pre-charge, constant-current, and constant-voltage charge. This device also manages the input power source by input current limit regulation and minimum input voltage regulation.

Using an I2C interface, the host can flexibly program the charge parameters. The device operating status can also be read in the registers.

Safety features include input over-voltage protection, battery under-voltage protection, thermal shutdown, and JEITA battery temperature monitoring.

The MP2695 is available in a 21-pin QFN (3mmx3mm) package.

Product Features

  • 4.0V to 11V Operation Voltage Range
  • Up to 16V Sustainable Input Voltage
  • 500mA to 3.6A Programmable Charge Current
  • 3.6V to 4.45V Programmable Charge Regulation Voltage with ±0.5% Accuracy
  • 100mA to 3A Programmable Input Current Limit with ±10% Accuracy
  • Minimum Input Voltage Loop for Maximum Adapter Power Tracking
  • Ultra-Low 25μA Battery Discharge Current in Idle Mode
  • Comprehensive Safety Features:
    • Fully-Customizable JEITA Profile with Programmable Temperature Threshold
    • Charge Safety Timer
    • Input Over-Voltage Protection
    • Thermal Shutdown
  • Analog Voltage Output IB Pin for Battery Current Monitor
  • Status and Fault Monitoring
  • Available in a Small QFN-21 (3mmx3mm) Package

Parametrics

  • Operating Vin (min) (V)4
  • Operating Vin (max) (V)11
  • Absolute Vin (max) (V)16
  • Cells1
  • GradeCatalog
  • NVDCNo
  • Vbatt (max) (V)4.45
  • Vbatt (min) (V)3.6
  • Battery TypeLi-Ion, Li-Polymer
  • Iin (max) (A)3
  • Icharge (max) (A)3.6
  • TopologyBuck
  • fsw (kHz)700/1200
  • Control InterfaceI2C
  • Special FeaturesJEITA Batt NTC Monitor
  • PackageQFN-21(3X3)
  • TimerYes
  • NTC MonitoringYes
  • EN ControlYes
  • Charge Status Yes

EV2695-Q-01A


I2C Controlled Single Cell Switching Charger

The EV2695-Q-01A is an evaluation board for the MP2695, a high-integrated, flexible switch-mode battery charger.

The MP2695 integrates full feature battery charging profile by three phases: pre-charge, constant current and constant voltage charge. This device also manages input power source by input current limit regulation and minimum input voltage regulation.

All the parameters and control can be easily accessed via the I2C interface.

$79.00 + tax


EVKT-MP2695


I2C-Controlled, Single-Cell Switching Charger with JEITA Profile

The EVKT-MP2695 is an evaluation kit for the MP2695. This kit is designed for the MP2695, which is a highly integrated, single-cell Li-ion/Li-polymer battery charger. Its layout accommodates most commonly used capacitors. The default function of this board is preset for charger mode, and the charge full voltage is preset to 4.200V for a single-cell Li-ion battery.

$100.00 + tax
