mEZD71210A-A

Active

4.5V - 17V Input, 1V Output, 10A, DC/DC Power Supply

  • Quantity Price
  • 1
    $9.06 /unit

In stock

Arrives 3-4 business days.
Shipping only $5 per order.


Talk to an Engineer or get a Quote
Upgrade to myMPS+

Product Description

The mEZD71210A is an open-frame, 4.5-17V input step-down power module with 10A continuous output current with 1.0V output voltage. It features output voltage and current readback, programmable current limit and frequency via I2C. It provides up to 93% peak efficiency.

Product Features

  • 4.5V to 17V Wide Operating Input
  • 10A Load Current
  • Hiccup Short-Circuit Protection
  • Over-/Under-Voltage Protection
  • Over-Current Protection
  • Over-Temperature Protection
  • Open Design Files and BOM

Parametrics

  • PGYes
  • SSInternal
  • Special FeaturesOCP, OTP, SCP
  • Package Size: WxL (mm)26.4x20
  • PackageSiP
  • GradeCatalog
  • Vout (min) (V)1
  • Vout (max) (V)1
  • Operating Temp Range (°C)-40
  • fsw (max) (kHz)500
  • Iout (max) (A)10
  • Vin (max) (V)17
  • Vin (min) (V)4.5
