Kintex Smallest Size Power Management Reference Design
REFERENCE DESIGN
Design Files:

For more information on reference designs
Response within 2 business days
AMD Xilinx part numbers:
- XCKU3
- XCKU5P
- XCKU9P
- XCKU11P
- XCKU13P
- XCKU15P
EVREF0103
MPS Products
Part Number | Quantity | Description |
MPM3695-25 | 2 | 16V, 20A, Scalable DC/DC Power Module with PMBus |
MPM3632C | 3 | 18V Input, 3A Module, Synchronous, Forced CCM, Step-Down Converter with Integrated Inductor |
MPM3683-7 | 3 | 2.7V-16V, 8A, Step-Down Power Module in QFN (7x7x4mm) Package |
MPM3606A | 1 | 21V Input, 0.6A Module Synchronous Step-down Converter with Integrated Inductor and PG pin |
MP20075 | 1 | 3A, DDR Termination Regulator |
