40V, 0.8A, Hex Half-Bridge Motor Driver with Serial Input Control Evaluation Board, AEC-Q100 Qualified

Datasheet

Description

The EVQ6626-F-00A is an evaluation board designed to demonstrate the capabilities of the MPQ6626-AEC1, a six half-bridge motor driver with serial input control. The input voltage (V_IN) ranges from 5.5V to 40V, with up to 0.8A of output current (I_OUT) capability.

The six half-bridges of the MPQ6626-AEC1 can be controlled separately via a standard serial data interface, and have various diagnostic functions, including those for shorted output, open load, over-temperature (OT), over-voltage (OV), and under-voltage (UV) conditions.

The MPQ6626-AEC1 has a very low quiescent current (I_Q) in standby mode, and requires a minimum number of readily available, standard external components. The MPQ6626-AEC1 is available in a TSSOP-28EP package, and is AEC-Q100 Grade 1 qualified.

The MPQ6626-AEC1 is suitable for motor drivers, telecommunication half-bridge power supplies, and avionics DC/DC converters.

Product Evaluated

Features & Benefits

Wide 5.5V to 40V Operating Input Voltage (V_IN) Range
High-Side (HS) and Low-Side (LS) Drivers Connected in Half-Bridge Configurations
Up to 0.8A of Output Current (I_OUT)
Typical 1.3Ω On Resistance (R_DS(ON)) (HS + LS)
Very Low Quiescent Current (I_Q) in Standby Mode vs. Total Temperature Range
Outputs are Short-Circuit Protected
Over-Temperature Protection (OTP) and Pre-Warning
Under-Voltage Lockout (UVLO) and Over-Voltage Lockout (OVLO)
Serial Data Interface
Diagnostic Functions Include:
- Shorted Output Conditions
- Open-Load Conditions
- Over-Temperature (OT) Conditions
- Over-Voltage (OV) Conditions
- Under-Voltage (UV) Conditions
Serial Interface Clock Frequency Up to 5MHz
Supports 3.3V and 5V Systems
Available in a TSSOP-28 EP Package
Available in AEC-Q100 Grade 1

Active Part Numbers:

EVQ6626-F-00A
