40V, 8A, Three-Phase BLDC Motor Driver with High-Side and Low-Side Logic Inputs Evaluation Board

Datasheet

Description

The EVQ6541A-QK-00A is an evaluation board designed to demonstrate the capabilities of the MPQ6541A-AEC1, a three-phase brushless DC (BLDC) motor driver. It operates across a wide 4.75V to 40V input voltage (V_IN) range.

The MPQ6541A-AEC1 has three integrated half-bridges consisting of six N-channel power MOSFETs. The rotor position information is provided by the Hall sensors assembled in the motor. The driver control signals are generated via an external controller, such as a microcontroller unit (MCU) or field-programmable gate array (FPGA).

The MPQ6541A-AEC1 is available in a QFN-26 (6mmx6mm) package.

Product Evaluated

Features & Benefits

Wide 4.75V to 40V Operating Input Voltage (V_IN) Range
Integrated Bidirectional Current-Sense Amplifiers
Supports 100% Duty Cycle Operation
High-Side (HS) and Low-Side (LS) Logic Inputs
Over-Current Protection (OCP) and Over-Temperature Protection (OTP)
Fault Indication
Available in a QFN-26 (6mmx6mm) Package

Active Part Numbers:

EVQ6541A-QK-00A

Buy direct from MPS

Standard Pricing

Quantity Price
1

$100.00 /unit

In stock

Arrives 3-4 business days. Shipping only $5 per order.

Quantity

100 Max per Company.
Limited Inventory to support product development.
